| Brand Name : | RESUN |
| Model Number : | R-8K-SL-02 |
| Certification : | EN 62109-1/2, EN 61000-6-1/2/3/4,IEC 62116, IEC 61727,IEC62183,PEA&MEA,NBR 16149, NBR 16150, PORTARIA Nº 140,515, NRS097 |
| Price : | Negotiable |
| Payment Terms : | T/T |
| Supply Ability : | 10000 |
| Delivery Time : | 3-30days |
• Support intelligent load dynamic access, automatically adjust
power allocation according to electricity demand, single-phase
hybrid design suitable for off grid/grid connected scenarios,
achieve efficient energy conversion and intelligent management.
• Equipped with intelligent load recognition and access functions,
it can accurately match the power consumption characteristics of
different devices. The parallel architecture supports flexible
capacity expansion, and the single-phase hybrid mode takes into
account AC/DC conversion, making it suitable for intelligent power
dispatch in distributed energy systems.
• A parallel inverter designed specifically for intelligent loads,
which can respond to load changes in real time and optimize energy
output. The single-phase hybrid technology is compatible with
multiple power inputs and supports independent operation off grid
or coordinated grid connection, enhancing the reliability and
flexibility of system power supply.
KEY STRENGTHS
• Max 20A input current to better match high power panel
• Max. 4 pcs parallel for on-grid and off-grid operation
| MODEL | R-8K-SL-02 |
| DC Input | |
| Max. PV Array Power [Wp]@STC | 16000 |
| Max. DC Voltage [V] | 500 |
| MPPT Voltage Range [V] | 90～480 |
| Rated DC Voltage [V] | 360 |
| Start Voltage [V] | 80 |
| Max. DC Input Current [A] | 40/40 |
| Max. DC Short Circuit Current [A] | 50/50 |
| No. of MPPT | 2 |
| Battery Parameters | |
| Battery Type | Lead-acid or LiFePO4 |
| Battery Voltage Range [V] | 40～60 |
| Max. Charging/Discharging Current [A] | 190 |
| AC Output [On-grid] | |
| Rated AC Power [W] | 8000 |
| Max. Apparent Power [VA] | 8800 |
| Rated Output Current [A]@230Vac | 34.8 |
| Max. Output Current [A] | 40 |
| Rated AC Voltage/Range [V] | L+N+PE, 220,230,240/180～280 |
| Rated Output Frequency/Range [Hz] | 50,60/45～55,55～65 |
| Power Factor [cos φ] | 0.8 leading～0.8 lagging |
| Total Harmonic Distortion [THDi] | <3% |
| AC Input [On-grid] | |
| Rated AC Voltage/Range [V] | L+N+PE, 220,230,240/180～280 |
| Rated Input Frequency [Hz] | 50,60 |
| Max. Input Current [A]@230Vac | 80 |
| AC Output [Back-up] | |
| Max.Output Power [VA] | 8000 |
| Max. Output Current [A] | 40 |
| Peak Output Apparent Power [VA] | 6000,60s |
| Rated AC Voltage/Range [V] | L+N+PE, 220,230,240/180～280 |
| Rated Output Frequency/Range [Hz] | 50,60/45～55,55～65 |
| Output THDv (@ Linear Load) | <3% |
| Efficiency | |
| Max. Efficiency | 97.6% |
| Euro Efficiency | 97.0% |
| Protection | |
| Battery Input Reverse Polarity Protection | Integrated |
| Over load Protection | Integrated |
| AC Short Circuit Current Protection | Integrated |
| DC Surge Protection | Integrated |
| AC Surge Protection | Integrated |
| Anti-islanding Protection | Integrated |
| AFCI Protection | Optional |
| RSD Protection | Optional |
| Interface | |
| PV Connection | Terminal Block |
| AC Connection | Terminal Block |
| Battery Connection | Terminal Block |
| Display | LED+APP |
| Communication | Wi-Fi/Ethernet/4G(Optional) |
| General Parameters | |
| Topology | Non-isolated |
| Operating Temperature Range | -40℃ to +60℃ (50℃ to 60℃ with derating) |
| Cooling Method | Intelligent Fan cooling |
| Ambient Humidity | 0-100% Non-condensing |
| Altitude | 4000m (>3000m Power Derating) |
| Noise [dBA] | <50 |
| Ingress Protection | IP65 |
| Dimensions [H*W*D] [mm] | 590*380*241 |
| Weight [kg] | 29 |
| Warranty [Year] | 5/10 |
| Standard | EN 62109-1/2, EN 61000-6-1/2/3/4,IEC 62116, IEC
61727,IEC62183,PEA&MEA,NBR 16149, NBR 16150, PORTARIA Nº 140,515, NRS097 |
|
|
